Cast Steel Gate, Globe, Check Valves Bolted Bonnet Design
The Cast Steel Gate, Globe, and Check Valves with Bolted Bonnet Design are engineered for reliable isolation, flow regulation, and backflow prevention in high-pressure industrial applications. The bolted bonnet construction provides a secure, leak-proof body-to-bonnet joint, ensuring safe operation, easy maintenance, and long-term performance in demanding service conditions.
Cast Steel Gate, Globe, Check Valves Bolted Bonnet Design
Manufactured from premium-quality cast steel and precision-machined components, these valves deliver exceptional strength, corrosion resistance, and dependable sealing performance. They are widely used in oil & gas, petrochemical, power generation, refineries, chemical processing, water treatment, and other critical industrial applications.
Key Features
- ✔️ Robust Cast Steel Bolted Bonnet Construction
- ✔️ Leak-Proof Body-to-Bonnet Gasket Joint
- ✔️ High Pressure & High Temperature Capability
- ✔️ Precision Machined Trim for Reliable Sealing
- ✔️ Renewable Seat Ring & Replaceable Components
- ✔️ Blow-Out Proof Stem for Enhanced Safety
- ✔️ Low Operating Torque with Smooth Operation
- ✔️ Available in Gate, Globe & Check Valve Designs
- ✔️ Manufactured to API, ASME & BS Standards
- ✔️ Long Service Life with Minimal Maintenance
Technical Specifications
| Parameter | Details |
|---|---|
| Sizes | 2`` to 36`` |
| Pressure Rating | ASME Class 600# | 800# | 900# | 1500# | 2500# | 4500# | Special Interpolated Classes |
| Connection | Socket Weld | Butt Weld | Flanged |
| Material | Cast Carbon Steel | Forged Carbon Steel | Low Alloy Steel | Stainless Steel | Special Alloys | Titanium |
| Operation | Manual | Electric Actuator | Pneumatic Actuator | Hydraulic Actuator |
| Bonnet Type | Pressure Seal Bonnet |
| Valve Type | T-Type | Y-Type | Angle | Elbow Down | Stop | Throttling | Stop Check | Piston Check |
